More about this product
Details:
- Maximum capacity: 800 lb/hr (363 kg/hr)
- Maximum allowable pressure (MAP) : 1000 PSIG @ 800° F (69 bar @ 427° C)
- Maximum operating pressure (MOP) : 1000 PSIG (69 bar)
- Maximum allowable temperature: 800° F (427° C)
- Connection type: screwed
- Connection size: 3/4"
- Orifice size: 5/64
- Body material: Carbon Steel ASTM A106 GR. B
-
Product Downloads
-
Manufacturer Info
Armstrong
