TS-2 - 3/4" NPT, 50 PSI, Straight Radiator Trap

The TS-2 has a balanced pressure thermostatic element with a high quality multiple convolution bellows. It’s ideal for draining equipment such as steam radiators and convectors, small heat exchangers, unit heaters and steam air vents. The TS-2 comes with a strong cast bronze body and a stainless seat. The valve and seat are renewable in-line.

Armstrong is a leading supplier of radiator steam traps. In a time when many manufacturers have overlooked this market segment, Armstrong continues to serve the special needs of homeowners, hotels, commercial buildings, schools, universities—anyone who uses steam radiators to heat their buildings.

Details:

• Maximum capacity: 1,600 lb/hr (726 kg/hr)
• Maximum allowable pressure (MAP) : 50 PSIG @ 300° F (3.4 bar @ 149° C)
• Maximum operating pressure (MOP) : 50 PSIG (3.4 bar)
• Connection type: screwed
• Connection Size: 3/4"
• Orifice Size: 5/16"
• Steam trap type: straight radiator trap
• Body material: ASTM B-62 bronze
